    3 Meter Height Automatic Paper Bag Making Machine with Two & Four Colours Printer

    Ask Lasest Price
    Brand Name : Tecon
    Model Number : HD
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 16 pcs per year
    Delivery Time : 3-5 Months Received Your Payment
    • Product Details
    • Company Profile

    3 Meter Height Automatic Paper Bag Making Machine with Two & Four Colours Printer

    Technical parameters of our production line:

    ZT9804S Tuber Machine


    Speed
    80~120 tubes/min(Depends on paper quality, number of ply and operators’ skill.)
    Tube length400~1400 mm
    Tube width380~620 mm
    Type of cuttingStep cut&Flat cut
    Number of ply2~4 paper + 1 PP/PE(Please specify if you need paper bag with PP film)
    Printing width1300 mm(MAX)
    Paper reel width660~1260 mm
    Paper reel diameterMax. 1, 300 mm
    Main drive motor47kw
    Size of whole set35.3m×2.4m×2.7m( L×W×H)
    Total weight32.5T


    HD4916B Bottomer

    Working speed80~130 bags/min
    Bag width420~600 mm
    Bag length520~880mm
    Bottom width90~130mm
    Distance between bottom centers420~780mm
    Valve sheet length100~250mm
    Valve sheet width120~170mm
    Main drive motor33kw
    Total weight22.7T


    ZT9804S Tuber Machine compose of following parts


    NameQuantity
    4-color printing machine1
    utomatic paper rectifier1
    Auxiliary paper driver1
    Perforation unit1
    Latitudinal gluing machine1
    Longitude gluing machine1
    Tubes forming unit1
    Driving tearing-off unit1
    Delivery and counting unit1
    Electric control system1 (Schneider)
    Air compressor1
    Servo system1


    HD4913 Bottomer machine compose of following parts


    NameQuantity
    High speed feeder machine1
    Perforation machine1
    Tube opening unit1
    Automatic gluing machine1
    Scrip sealing machine1
    Bag bottom turning unit1
    Counting and delivery line1
    Piling up platform1
    Electric control unit1
    Delivery and counting unit1
    Electric control system1 (Schneider, German)
    Vacuum-pump1 (Schneider, German)
    Outside reinforcement sheet1

    Operating condition

    Working hour : 8~22 hours/day

    Design temperature : 0~40℃

    Design humidity : MAX. 95%

    Number required : 1 unit

    Model name : ZT9804


    Performance

    Speed : 130~150 tubes/min

    (Depends on paper quality, number of ply and operators’ skill.)

    Tube length : 700~1005 mm

    A Shape Tube width : 470~580 mm

    Space between tape steps : 20 mm

    Number of ply : 2~4 paper + 1 PP/PE(Please specify if you need paper bag with PP film

    Diameter of print roller :ø144~ø314 mm

    Printing width :1300 mm(MAX)

    Paper reel width : 860~1260 mm

    Paper reel diameter : Max. 1, 300 mm

    Air consumption : 1,100L/min

    Main drive motor : 30kw

    Size of Tuber machine : 34.3m×2.8m×2.7m ( L×W×H)

    Total weight : 30.5T


    Bottomer machine’s technological process

    Brand Name:Tecon
    Model Number:ZT9804
    Certification:CE
    Place of Origin:China

    Total Weight30TMain drive motor30KW
    Size34.3m×2.4m×2.7m( L×W×H)Air consumption1,100L/min
    Working hour22 hours/dayDesign temperature0~40℃
